| Specifications
| Product Glance | |
| Model | KS3 |
| Version | KS1-10 |
| Algorithm | Cryptocurrency | kHeavyHash | KAS |
| Hashrate, TH/s(1-1) | 8.2 |
| Power on wall @25°C, Watt(1-1) | 3050 |
| Power efficiency on wall @25°C, J/T(1-1) | 372 |
| Detailed Characteristics | |
| Power Supply | |
| Power supply AC Input voltage range V(2-1) | 200~240V AC |
| Power supply AC Input Frequency Range, Hz | 50~60 |
| Power supply AC Input current, Amp(2-2) | 20 |
| Adapted AC Output power requirment W(2-3) | 3600 |
| Hardware Configuration | |
| Quantity of hash chips | 276 |
| Quantity of hash boards | 3 |
| Networking connection mode | RJ45 Ethernet 10/100M |
| Miner Size (Length*Width*Height, w/o package),mm | 430*195.5*290 |
| Miner Size (Length*Width*Height, with package),mm | 570*316*430 |
| Net weight, kg | 15.2 |
| Gross weight, kg | 16.9 |
| Noise,dBA@25°C(2-4) | 70 |
| Environment Requirements | |
| Operation temperature,°C | 0~40 |
| Storage temperature,°C | -20~70 |
| Operation humidity(non-condensing) , RH | 10~90% |
| Operation altitude, m(2-5) | ≤2000 |
NOTE:
1.If the user fails to use the product in accordance with the given instructions, specifications, and conditions provided, or change the function setting without CryptominingHub’s prior consent, CryptominingHub will not be liable for any damage arising therefrom.
(1-1) The Hashrate value, Power on wall, and Power efficiency on wall are all typical values.The actual Hashrate value fluctuates by -3%, and the actual Power on wall and Power efficiency on wall fluctuate by +5%.
(2-1) Caution: Wrong input voltage may cause server damaged.
(2-2) Three-phase AC input, 10 A per wire.
(2-3) Caution: It is strongly recommended that the power on wall ofthe miner does not exceed this value.
(2-4) Max condition: Fan is under max RPM(rotation per minute).
(2-5) When the miner is used at an altitude from 900m to 2000m, the highest operating temperature decreases by 1°C for every increase of 300m.
| Purchasing Guidelines
1.The shipping costs, cutsoms charges, and taxes(if any) are not included in the retail price shown above.
2.After an order has been submitted, a request to cancel the order, refund any part of the ordered amount or change the ordered item(s) to different item(s) or different batch(es) will not be entertained by Bitmern Mining.
3.The pictures shown are for reference only; the final shipment version shall prevail.
| Shipping Details
1. The products are made in China. If shipping to the U.S., customers will need to pay an extra 25% tariff.
2. Shipments will be scheduled on a first-paid-first-ship basis for orders on which Bitmern Mining has received full payment.
3. You are responsible for any customs delays or returned shipments due to a lack of proper documentation. It’s highly recommended to be aware of local customs clearance policies and to prepare all customs documentation ahead of time to avoid any customs clearance delays or unexpected costs.
